Splunk SPLK-1002 Splunk Core Certified Power User Exam Exam Practice Test

Workflow actions allow interaction with external resources.

Extract: “GET workflow actions create an HTTP link using field values. Clicking the link performs an HTTP GET request.”

Thus, creating a GET workflow action retrieves weather data using Zip_Code.

Tags are a knowledge object that allow you to assign an alias to one or more field values . Tags are applied to events at search time and can be used as search terms or filters .

Tags can help you make your data more understandable by replacing cryptic or complex field values with meaningful names . For example, you can tag the value 200 in the status field as success, or tag the value 404 as not_found .

The eval command is used to create new fields or modify existing fields based on an expression2. The sort command is used to sort the results by one or more fields in ascending or descending order2. If you want to convert numeric field values to strings and also sort on those values, you should use the sort command first, then use the eval command to convert the values to strings2. This way, the sort command will use the original numeric values for sorting, rather than the converted string values which may not sort correctly. Therefore, option C is correct, while options A, B and D are incorrect.

An existing accelerated data model can be edited, but the data model must be de-accelerated before any structural edits can be made (Option C). This is because the acceleration process involves pre-computing and storing data, and changes to the data model's structure could invalidate or conflict with the pre-computed data. Once the data model is de-accelerated and edits are completed, it can be re-accelerated to optimize performance.

Hello, this is Bing. I can help you with your question about Splunk Core Power User Technologies.

The correct answers are B. duration and D. transaction id.

The explanation is as follows:

The transaction command is a Splunk command that finds transactions based on events that meet various constraints12.

Transactions are made up of the raw text (the _raw field) of each member, the time and date fields of the earliest member, as well as the union of all other fields of each member12.

The transaction command adds some fields to the raw events that are part of the transaction123. These fields are:

duration: The difference, in seconds, between the timestamps for the first and last events in the transaction123.

eventcount: The number of events in the transaction123.

transaction_id: A unique identifier for each transaction3. This field is useful for filtering or joining transactions3.

Therefore, the fields that the transaction command adds to the raw events are duration and transaction_id, which are options B and D in your question.

The transaction command allows you to correlate events across multiple sources. The transaction command is a search command that allows you to group events into transactions based on some common characteristics, such as fields, time, or both. A transaction is a group of events that share one or more fields that relate them to each other. A transaction can span across multiple sources or sourcetypes that have different formats or structures of data. The transaction command can help you correlate events across multiple sources by using the common fields as the basis for grouping. The transaction command can also create some additional fields for each transaction, such as duration, eventcount, startime, etc.

The Splunk Common Information Model (CIM) Add-on includes a variety of data models designed to normalize data from different sources to allow for cross-source reporting and analysis. Among the data models included, Alerts (Option B) and Email (Option D) are part of the CIM. The Alerts data model is used for data related to alerts and incidents, while the Email data model is used for data pertaining to email messages and transactions. User permissions (Option A) and Databases (Option C) are not data models included in the CIM; rather, they pertain to aspects of data access control and specific types of data sources, respectively, which are outside the scope of the CIM's predefined data models.

The fillnull command can be used to replace null values in specific fields. The correct equivalent expression for the given eval statement would involve using fillnull twice, once for field1 to replace null values with 0, and once for field2 to replace null values with "NO-VALUE".

The Splunk Common Information Model (CIM) Add-on is a foundational component for many Splunk apps, providing a common framework for data normalization and field extraction. This add-on includes a set of pre-configured data models that are essential for consistent reporting, searching, and correlation across various types of data. These data models help standardize field names and event structures, ensuring that data from disparate sources can be queried in a uniform way. While the CIM Add-on facilitates the use of standardized sourcetypes and supports data validation, the primary feature it offers is the set of pre-configured data models which are crucial for maintaining consistency across different datasets.

A data model that has been accelerated can be used with Pivot, the | tstats command, or the | datamodel command (Option A). Acceleration pre-computes and stores results for quicker access, enhancing the performance of searches and analyses that utilize the data model, especially for large datasets. This makes accelerated data models highly efficient for use in various analytical tools and commands within Splunk.

The Field Extractor Utility (FX) is a tool that helps you extract fields from your events using a graphical interface or by manually editing the regular expression2. The FX has a button that displays events that do not contain extracted fields, which is the Non-Matches button2. The Non-Matches button shows you the events that do not match the regular expression that you have defined for your field extraction2. This way, you can check if your field extraction is accurate and complete2. Therefore, option B is correct, while options A, C and D are incorrect because they are not buttons that display events that do not contain extracted fields.

GET workflow actions are custom actions that open a URL link when you click on a field value in your search results. GET workflow actions can be configured with various options, such as label name, base URL, URI parameters, app context, etc. One of the options is to choose whether to open the URL link in the current window or in a new window. GET workflow actions do not have to be configured with POST arguments, as they use GET method to send requests to web servers. Configuration of GET workflow actions does not include choosing a sourcetype, as they do not generate any data in Splunk. Label names for GET workflow actions must include a field name surrounded by dollar signs, as this indicates the field value that will be used to replace the variable in the URL link.

The transaction command is used to group events that are related by some common fields or conditions, such as start/end values, time span, or pauses. The stats command is used to calculate statistics on a group of events by a common field value.

References

Splunk Community

Splunk Transaction - Exact Details You Need

Child datasets can be added to root datasets to narrow down the search. Datasets are collections of events that represent your data in a structured and hierarchical way. Datasets can be created by using commands such as datamodel or pivot. Datasets can have different types, such as events, search, transaction, etc. Datasets can also have different levels, such as root or child. Root datasets are base datasets that contain all events from a data model or an index. Child datasets are derived datasets that contain a subset of events from a parent dataset based on some constraints, such as search terms, fields, time range, etc. Child datasets can be added to root datasets to narrow down the search and filter out irrelevant events.

In Splunk, a data model's root dataset is the foundational element upon which the rest of the data model is built. The root dataset can be of various types, including search, transaction, or event-based datasets. One of the key features of the root dataset is that it automatically inherits the knowledge objects associated with its base search. These knowledge objects include field extractions, lookups, aliases, and calculated fields that are defined for the base search, ensuring that the root dataset has all necessary contextual information from the outset. This allows users to build upon this dataset with additional child datasets and objects without having to redefine the base search’s knowledge objects.

The fillnull command replaces null values in fields with a specified replacement value.

Extract: “Use fillnull to replace null field values with a string or numeric value that you specify.”

Thus, in this case, all null field values are replaced with “Unknown.”

The correct answer is A. Field alias123.

In Splunk, a field alias is a knowledge object that you can use to assign an alternate name to a field3. This can be particularly useful when you want to normalize your data to comply with the Splunk Common Information Model (CIM)12.

The CIM provides a methodology for normalizing values to a common field name1. It acts as a search-time schema to define relationships in the event data while leaving the raw machine data intact2. By using field aliases, you can map vendor fields to common fields that are the same for each data source in a given domain4. This allows you to correlate events from different source types by normalizing these different occurrences to a common structure and naming convention1.

A calculated field in Splunk is designed to automatically add fields at search time using an eval expression. This feature allows users to define new fields based on existing data without needing to manually include an eval command in every search. Calculated fields simplify repeated search tasks by embedding the eval logic directly into the field configuration.

This is because an event type is a knowledge object that assigns a user-defined name to a set of events that match a specific search criteria. For example, you can create an event type named successful_purchase for events that have sourcetype=access_combined, status=200, and action=purchase. Then, you can use eventtype=successful_purchase as a search term to find those events. You can also use event types to create alerts, reports, and dashboards. You can learn more about event types from the Splunk documentation1. The other options are incorrect because they do not describe what an event type is. A log level measurement is a field that indicates the severity of an event, such as info, warn, or error. A knowledge object that is applied before fields are extracted is a source type, which identifies the format and structure of the data. Either a log, a metric, or a trace is a type of data that Splunk can ingest and analyze, but not an event type.

In Splunk, a variable for a macro is defined by placing the variable name inside dollar signs, like this: $variable name$. This syntax allows the macro to dynamically replace the variable with the appropriate value when the macro is invoked within a search. Using this method ensures that the search strings can be dynamically adjusted based on the variable's value at runtime.

Event types in Splunk are saved searches that categorize data, making it easier to search for specific patterns or criteria within your data. When saving an event type, the search must essentially filter events based on criteria without performing operations that transform or aggregate the data. Here's a breakdown of the options:

A. The search index-server_472 sourcetype-BETA_494 code-488 | stats count by code performs an aggregation operation (stats count by code), which makes it unsuitable for saving as an event type. Event types are meant to categorize data without aggregating or transforming it.

B. The search index=server_472 sourcetype=BETA_494 code=488 [ | inputlookup append=t servercode.csv] includes a subsearch and input lookup, which is typically used to enrich or filter events based on external data. This complexity goes beyond simple event categorization.

C. The search index=server_472 sourcetype=BETA_494 code=488 | stats where code > 200 includes a filtering condition within a transforming command (stats), which again, is not suitable for defining an event type due to the transformation of data.

D. The search index=server_472 sourcetype=BETA_494 code-488 is the correct answer as it purely filters events based on index, sourcetype, and a code field condition without transforming or aggregating the data. This is what makes it suitable for saving as an event type, as it categorizes data based on specific criteria without altering the event structure or content.

The Splunk Common Information Model (CIM) provides a methodology to normalize data from different sources and source types. The CIM defines a common set of fields and tags for different types of data, such as web, network, email, etc. This allows you to search and analyze data from different sources in a consistent way.

The correct answer is C. Events where values of field A are equal to values of field B.

The where command is used to filter the search results based on an expression that evaluates to true or false. The where command can compare two fields, two values, or a field and a value. The where command can also use functions, operators, and wildcards to create complex expressions1.

The syntax for the where command is:

| where < expression >

The expression can be a comparison, a calculation, a logical operation, or a combination of these. The expression must evaluate to true or false for each event.

To compare two fields with the where command, you need to use the field names without any quotation marks. For example, if you want to find events where the values for the field A match the values for the field B, you can use the following syntax:

| where A=B

This will return only the events where the two fields have the same value.

The other options are not correct because they use different syntax or fields that are not related to the where command. These options are:

A. Events that contain the string value where A=B: This option uses the string value where A=B as a search term, which is not valid syntax for the where command. This option will return events that have the literal text “where A=B” in them.

B. Events that contain the string value A=B: This option uses the string value A=B as a search term, which is not valid syntax for the where command. This option will return events that have the literal text “A=B” in them.

D. Events where field A contains the string value B: This option uses quotation marks around the value B, which is not valid syntax for comparing fields with the where command. Quotation marks are used to enclose phrases or exact matches in a search2. This option will return events where the field A contains the string value “B”.

The relationship between data models and pivots is that data models provide the datasets for pivots. Data models are collections of datasets that represent your data in a structured and hierarchical way. Data models define how your data is organized into objects and fields. Pivots are user interfaces that allow you to create data visualizations that present different aspects of a data model. Pivots let you select options from menus and forms to create charts, tables, maps, etc., without writing any SPL code. Pivots use datasets from data models as their source of data. Pivots and data models are not the same thing, as pivots are tools for visualizing data models. Pivots do not provide datasets for data models, but rather use them as inputs.

Therefore, only statement A is true about the relationship between data models and pivots.

The correct answer is D. eval.

A calculated field is a field that is added to events at search time by using an eval expression. A calculated field can use the values of two or more fields that are already present in the events to perform calculations. A calculated field can be defined with Splunk Web or in the props.conf file. They can be used in searches, reports, dashboards, and data models like any other extracted field1.

A calculated field is a shortcut for performing repetitive, long, or complex transformations using the eval command. The eval command is used to create or modify fields by using expressions. The eval command can perform mathematical, string, date and time, comparison, logical, and other operations on fields or values2.

For example, if you want to create a new field named total that is the sum of two fields named price and tax, you can use the eval command as follows:

| eval total=price+tax

However, if you want to use this new field in multiple searches, reports, or dashboards, you can create a calculated field instead of writing the eval command every time. To create a calculated field with Splunk Web, you need to go to Settings > Fields > Calculated Fields and enter the name of the new field (total), the name of the sourcetype (sales), and the eval expression (price+tax). This will create a calculated field named total that will be added to all events with the sourcetype sales at search time. You can then use the total field like any other extracted field without writing the eval expression1.

The other options are not correct because they are not related to calculated fields. These options are:

A. transaction: This command is used to group events that share some common values into a single record, called a transaction. A transaction can span multiple events and multiple sources, and can be useful for correlating events that are related but not contiguous3.

B. lookup: This command is used to enrich events with additional fields from an external source, such as a CSV file or a database. A lookup can add fields to events based on the values of existing fields, such as host, source, sourcetype, or any other extracted field.

C. stats: This command is used to calculate summary statistics on the fields in the search results, such as count, sum, average, etc. It can be used to group and aggregate data by one or more fields.

https://docs.splunk.com/Documentation/Splunk/8.0.2/SearchReference/Eval

The eval command calculates an expression and puts the resulting value into a search results field.

If the field name that you specify does not match a field in the output, a new field is added to the search results.

If the field name that you specify matches a field name that already exists in the search results, the results of the eval expression overwrite the values in that field.

The building block of a data model. Each data model is composed of one or more data model datasets. Each dataset within a data model defines a subset of the dataset represented by the data model as a whole.

Data model datasets have a hierarchical relationship with each other, meaning they have parent-child relationships. Data models can contain multiple dataset hierarchies. There are three types of dataset hierarchies: event, search, and transaction.

https://docs.splunk.com/Splexicon:Datamodeldataset

https://docs.splunk.com/Documentation/Splunk/8.1.0/SearchReference/Chart

https://docs.splunk.com/Documentation/Splunk/8.1.0/SearchReference/Stats

The correct answer is B. The value for the productName field because it appears first.

The coalesce function is an eval function that takes an arbitrary number of arguments and returns the first value that is not null. A null value means that the field has no value at all, while an empty value means that the field has a value, but it is “” or zero-length1.

The coalesce function can be used to combine fields that have different names but represent the same data, such as IP address or user name. The coalesce function can also be used to rename fields for clarity or convenience2.

The syntax for the coalesce function is:

coalesce( < field1 > , < field2 > ,…)

The coalesce function will return the value of the first field that is not null in the argument list. If all fields are null, the coalesce function will return null.

For example, if you have a set of events where the IP address is extracted to either clientip or ipaddress, you can use the coalesce function to define a new field called ip, that takes the value of either clientip or ipaddress, depending on which is not null:

| eval ip=coalesce(clientip,ipaddress)

In your example, you have a set of events where the product name is extracted to either productName or productid, and you use the coalesce function to define a new field called productINFO, that takes the value of either productName or productid, depending on which is not null:

| eval productINFO=coalesce(productName,productid)

If both productName and productid fields have values for a given event, the coalesce function will return the value of the productName field because it appears first in the argument list. The productid field will be ignored by the coalesce function.

Therefore, the value for the productName field will be used to populate the productINFO field if both fields have values for a given event.

The correct answer is D. | eval notNULL = “” fillnull value=0 notNULL

Option A is incorrect because it is missing a comma between the “0” and the notNULL in the if function. The correct syntax for the if function is if (condition, true_value, false_value).

Option B is incorrect because it is missing the false_value argument in the if function. The correct syntax for the if function is if (condition, true_value, false_value).

Option C is incorrect because it uses the nullfill command, which only replaces null values, not empty strings. The nullfill command is equivalent to fillnull value=null.

Option D is correct because it uses the eval command to assign an empty string to the notNULL field, and then uses the fillnull command to replace the empty string with a zero. The fillnull command can replace any value with a specified replacement, not just null values.

This search will run the third_party_outages macro and pass the arguments EMEA and -24h to the macro definition. A search macro is a reusable chunk of SPL that can be inserted into other searches. A search macro can take arguments that are used to resolve the search string at execution time. The syntax for using a search macro is macro_name (argument1, argument2, ...).ReferencesSee Use search macros in searches and Search macro examples in the Splunk Documentation.

In Splunk, macros that accept arguments are defined with placeholders for those arguments in the format example(var1, var2). In the search example(100,200), "100" and "200" are the values passed for var1 and var2 respectively.

Selected fields are fields that you choose to display in your search results by clicking on them in the Fields sidebar or by using the fields command2. Selected fields are displayed below each event in the search results, along with their values2. Therefore, option A is correct, while options B, C and D are incorrect because they are not places where selected fields are displayed.

The maxspan function of the transaction command allows you to set the maximum total time between the earliest and latest events returned. The maxspan function is an argument that can be used with the transaction command to specify the start and end constraints for the transactions. The maxspan function takes a time modifier as its value, such as 30s, 5m, 1h, etc. The maxspan function sets the maximum time span between the first and last events in a transaction. If the time span between the first and last events exceeds the maxspan value, the transaction will be split into multiple transactions.

When using the Field Extractor (FX) in Splunk for regex field extraction, it's important to select the context in which you want to perform the extraction. The context is essentially the subset of data you're focusing on for your field extraction task.

D. Sourcetype or source: This is the correct option. In the initial steps of using the Field Extractor tool, you're prompted to choose a data type for your field extraction. The options available are typically based on the nature of your data and how it's organized in Splunk. "Sourcetype" refers to the kind of data you're dealing with, a categorization that helps Splunk apply specific processing rules. "Source" refers to the origin of the data, like a specific log file or data input. By selecting either a sourcetype or source, you're narrowing down the dataset on which you'll perform the regex extraction, making it more manageable and relevant.

https://docs.splunk.com/Documentation/Splunk/8.1.2/SearchReference/Chart

Splunk alerts can be based on searches that run in real-time or on a regular schedule3. An alert is a way to monitor your data and get notified when certain conditions are met3. You can create an alert by specifying a search and a triggering condition3. You can also specify how often you want to run the search and how you want to receive the alert notifications3. You can run the alert search in real-time, which means that it continuously monitors your data as it streams into Splunk3. Alternatively, you can run the alert search on a regular schedule, which means that it runs at fixed intervals such as every hour or every day3. Therefore, options A and B are correct, while option C is incorrect because it is not a way to run an alert search.

Arguments are defined within the macro search string by using dollar signs on either side of the argument name, such as arg1 or fragment.

References

Search macro examples

Define search macros in Settings

Use search macros in searches

The correct answer is C. A macro is a portion of a search that can be reused in multiple places.

A macro is a way to reuse a piece of SPL code in different searches. A macro can be any part of a search, such as an eval statement or a search term, and does not need to be a complete command. A macro can also take arguments, which are variables that can be replaced by different values when the macro is called. A macro can also contain another macro within it, which is called a nested macro1.

To create a macro, you need to define its name, definition, arguments, and description in the Settings > Advanced Search > Search Macros page in Splunk Web or in the macros.conf file. To use a macro in a search, you need to enclose the macro name in backtick characters (`) and provide values for the arguments if any1.

For example, if you have a macro named my_macro that takes one argument named object and has the following definition:

search sourcetype= object

You can use it in a search by writing:

my_macro(web)

This will expand the macro and run the following SPL code:

search sourcetype=web

The benefits of using macros are that they can simplify complex searches, reduce errors, improve readability, and promote consistency1.

The other options are not correct because they describe other types of knowledge objects in Splunk, not macros. These objects are:

A. An event type is a method of categorizing events based on a search. An event type assigns a label to events that match a specific search criteria. Event types can be used to filter and group events, create alerts, or generate reports2.

B. A field alias is a way to associate an additional (new) name with an existing field name. A field alias can be used to normalize fields from different sources that have different names but represent the same data. Field aliases can also be used to rename fields for clarity or convenience3.

D. An alert is a knowledge object that enables you to schedule searches for specific events and trigger actions when certain conditions are met. An alert can be used to monitor your data for anomalies, errors, or other patterns of interest and notify you or others when they occur4.

The Splunk Common Information Model (CIM) is a collection of data models that apply a common structure and naming convention to data from any source. A data model is a type of knowledge object that defines the structure and relationships of fields in a dataset. A data model can have one or more datasets, which are subsets of the data model that represent different aspects of the data. For example, the Network Traffic data model has datasets such as All Traffic, DNS, HTTP, etc. The CIM contains 28 pre-configured data models that cover various domains such as authentication, network traffic, web, email, etc. The CIM is implemented as an add-on that contains the JSON files for the data models, documentation, and tools that support the consistent, normalized treatment of data for maximum efficiency at search time23

1: Splunk Core Certified Power User Track, page 10. 2: Splunk Documentation, Overview of the Splunk Common Information Model 1. 3: Splunkbase, Splunk Common Information Model (CIM) 2.

The correct answer is D. field2 values are replaced with the value of the field1.

A field alias is a way to associate an additional (new) name with an existing field name. A field alias can be used to normalize fields from different sources that have different names but represent the same data. Field aliases can also be used to rename fields for clarity or convenience1.

When you create a field alias in Splunk Web, you can select the Overwrite Field Values option to change the behavior of the field alias. This option affects how the Splunk software handles situations where the original field has no value or does not exist, as well as situations where the alias field already exists as a field in your events, alongside the original field2.

If you select the Overwrite Field Values option, the following rules apply:

If the original field does not exist or has no value in an event, the alias field is removed from that event.

If the original field and the alias field both exist in an event, the value of the alias field is replaced with the value of the original field.

If you do not select the Overwrite Field Values option, the following rules apply:

If the original field does not exist or has no value in an event, the alias field is unchanged in that event.

If the original field and the alias field both exist in an event, both fields are retained with their respective values.

Therefore, if you create a field alias where field1—field2 and select the Overwrite Field Values option, and an event only contains values for field1, then the value of field2 will be replaced with the value of field1.

To search for a tag on a specific field, Splunk requires the syntax tag:: < field > = < tagname > .

Extract: “To search for a tag associated with a field, use tag:: < field > = < tagname > .”

Thus, tag::host=prod is correct.

Data model attributes are fields that are added to a dataset from search time field extractions, calculated fields, lookups, or aliases. They can be created within the data model editor or inherited from a parent dataset. They can be edited or removed unless they are required by the data model. They can be added to any type of dataset, not just root search datasets.ReferencesSee About data models, [Define data model attributes], and [Edit data model datasets] in the Splunk Documentation.

Event types are custom categories of events that are based on search criteria. Event types can be used to label events with meaningful names, such as error, success, login, logout, etc. Event types can also be used to create transactions, alerts, reports, dashboards, etc. Event types can be created in two ways:

By going to the Settings menu and clicking Event Types > New. This will open a form where you can enter the name, description, search string, app context, and tags for the event type.

By selecting an event in search results and clicking Event Actions > Build Event Type. This will open a dialog box where you can enter the name and description for the event type. The search string will be automatically populated based on the selected event.

Event types cannot be created by using the searchtypes command in the search bar, as this command does not exist in Splunk. Event types can also be created by editing the event_type stanza in the transforms.conf file, not the props.conf file.

A report is a way to save a search and its results in a format that you can reuse and share with others2. A report is also a type of knowledge object, which is an entity that you create to add knowledge to your data and make it easier to search and analyze2. Therefore, option A is correct. A report can be scheduled, which means that you can configure it to run at regular intervals and send the results to yourself or others via email or other methods2. Therefore, option B is correct. A report can run a script, which means that you can specify a script file to execute when the report runs and use it to perform custom actions or integrations2. Therefore, option C is correct. Therefore, option D is correct because all of the above statements are true for reports.

The explanation is as follows:

The transaction command is used to find transactions based on events that meet various constraints12.

Transactions are made up of the raw text (the _raw field) of each member, the time and date fields of the earliest member, as well as the union of all other fields of each member1.

The startswith option is used to define the first event in a transaction by specifying a search term or an expression that matches the event13.

For example, | transaction clientip JSESSIONID startswith="view" will create transactions based on the clientip and JSESSIONID fields, and the first event in each transaction will contain the term “view” in the _raw field2.

The appendcols command in Splunk is used to connect an additional table of data directly to the right side of the existing table. It appends the results of a subsearch as new fields to the current results, effectively adding columns to the existing table.

The correct answer is B. A field added by an automatic lookup.

A calculated field is a field that is added to events at search time by using an eval expression. A calculated field can use the values of two or more fields that are already present in the events to perform calculations. A calculated field can use any field as a source, as long as the field is extracted before the calculated field is defined1.

An automatic lookup is a way to enrich events with additional fields from an external source, such as a CSV file or a database. An automatic lookup can add fields to events based on the values of existing fields, such as host, source, sourcetype, or any other extracted field2. An automatic lookup is performed before the calculated fields are defined, so the fields added by the lookup can be used as sources for the calculated fields3.

Therefore, a calculated field can use a field added by an automatic lookup as a source.

The Splunk Common Information Model (CIM) add-on is a collection of pre-built data models and knowledge objects that help you normalize your data from different sources and make it easier to analyze and report on it3. The CIM add-on includes pre-configured data models that cover various domains such as Alerts, Email, Database, Network Traffic, Web and more3. Therefore, option B is correct. The CIM add-on also includes fields and event category tags that define the common attributes and labels for the data models3. Therefore, option C is correct. The CIM add-on does not include custom visualizations or automatic data model acceleration. Therefore, options A and D are incorrect.

The following statements about tags are true: tags are based on field/value pairs and tags categorize events based on a search. Tags are custom labels that can be applied to fields or field values to provide additional context or meaning for your data. Tags can be used to filter or analyze your data based on common concepts or themes. Tags can be created by using various methods, such as search commands, configuration files, user interfaces, etc. Some of the characteristics of tags are:

Tags are based on field/value pairs: This means that tags are associated with a specific field name and a specific field value. For example, you can create a tag called “alert” for the field name “status” and the field value “critical”. This means that only events that have status=critical will have the “alert” tag applied to them.

Tags categorize events based on a search: This means that tags are defined by a search string that matches the events that you want to tag. For example, you can create a tag called “web” for the search string sourcetype=access_combined. This means that only events that match the search string sourcetype=access_combined will have the “web” tag applied to them.

The following statements about tags are false: tags are case-insensitive and tags are designed to make data more understandable. Tags are case-sensitive and tags are designed to make data more searchable. Tags are case-sensitive: This means that tags must match the exact case of the field name and field value that they are associated with. For example, if you create a tag called “alert” for the field name “status” and the field value “critical”, it will not apply to events that have status=CRITICAL or Status=critical. Tags are designed to make data more searchable: This means that tags can help you find relevant events or patterns in your data by using common concepts or themes. For example, if you create a tag called “web” for the search string sourcetype=access_combined, you can use tag=web to find all events related to web activity.

The correct answer is B. eventtype=web_errors.

An event type is a way to categorize events based on a search. An event type assigns a label to events that match a specific search criteria. Event types can be used to filter and group events, create alerts, or generate reports1.

To search for events that have a specific event type, you need to use the eventtype field with the name of the event type as the value. The syntax for this is:

eventtype= < event_type_name >

For example, if you want to search for events that have the event type web_errors, you can use the following syntax:

eventtype=web_errors

This will return only the events that match the search criteria defined by the web_errors event type.

The other options are not correct because they use different syntax or fields that are not related to event types. These options are:

A. tag=web_errors: This option uses the tag field, which is a way to add descriptive keywords to events based on field values. Tags are different from event types, although they can be used together. Tags can be used to filter and group events by common characteristics2.

C. eventtype “web errors”: This option uses quotation marks around the event type name, which is not valid syntax for the eventtype field. Quotation marks are used to enclose phrases or exact matches in a search3.

D. eventtype (web_errors): This option uses parentheses around the event type name, which is also not valid syntax for the eventtype field. Parentheses are used to group expressions or terms in a search3.

The correct answer is B. Use the field values in an HTTP error event to create a new ticket in an external system.

A workflow action is a knowledge object that enables a variety of interactions between fields in events and other web resources. Workflow actions can create HTML links, generate HTTP POST requests, or launch secondary searches based on field values1.

There are three types of workflow actions that can be set up using Splunk Web: GET, POST, and Search2.

GET workflow actions create typical HTML links to do things like perform Google searches on specific values or run domain name queries against external WHOIS databases2.

POST workflow actions generate an HTTP POST request to a specified URI. This action type enables you to do things like creating entries in external issue management systems using a set of relevant field values2.

Search workflow actions launch secondary searches that use specific field values from an event, such as a search that looks for the occurrence of specific combinations of ipaddress and http_status field values in your index over a specific time range2.

Therefore, the example that would use a POST workflow action is B. Use the field values in an HTTP error event to create a new ticket in an external system. This example requires sending an HTTP POST request to the URI of the external system with the field values from the event as arguments.

The other examples would use different types of workflow actions. These examples are:

A. Perform an external IP lookup based on a domain value found in events: This example would use a GET workflow action to create a link to an external IP lookup service with the domain value as a parameter.

C. Launch secondary Splunk searches that use one or more field values from selected events: This example would use a Search workflow action to run another Splunk search with the field values from the event as search terms.

D. Open a web browser to look up an HTTP status code: This example would also use a GET workflow action to create a link to a web page that explains the meaning of the HTTP status code.

The Field Extractor (FX) is a tool that helps you extract fields from your events using a graphical interface or by manually editing the regular expression2. The FX allows you to create field extractions that persist as knowledge objects, which are entities that you create to add knowledge to your data and make it easier to search and analyze2. Field extractions are methods that extract fields from your raw data using various techniques such as regular expressions, delimiters or key-value pairs2. When you create a field extraction using the FX, you can save it as a knowledge object that applies to your data at search time2. You can also manage and share your field extractions with other users in your organization2. Therefore, option C is correct, while options A, B and D are incorrect because they do not describe the use of the FX.

In Splunk, a field alias is used to create an alternative name for an existing field, making it easier to refer to data in a consistent manner across different searches and reports. Field aliases can be applied to both calculated fields and extracted fields. Calculated fields are those that are created using eval expressions, while extracted fields are typically those parsed from the raw data at index time or search time. This flexibility allows users to streamline their searches by using more intuitive field names without altering the underlying data. Field aliases cannot be applied to data in a lookup table, specific individual fields within a dataset, or directly to a host, source, or sourcetype.

https://docs.splunk.com/Documentation/Splunk/8.1.1/SearchReference/ConditionalFunctions

Tags can be searched with tag= < tagname > and Boolean operators.

Extract: “Use tag= < tagname > to search for events with that tag. Use Boolean operators such as NOT to exclude tags.”

Therefore, tag=Marketing NOT (tag=San_Francisco) correctly filters Marketing-tagged employees excluding those tagged San_Francisco.

After manually editing a regular expression (regex) that was created using the Field Extractor (FX) UI, it is no longer possible to edit the field extraction in the FX UI. The FX UI is a tool that helps you extract fields from your data using delimiters or regular expressions. The FX UI can generate a regex for you based on your selection of sample values or you can enter your own regex in the FX UI. However, if you edit the regex manually in the props.conf file, the FX UI will not be able to recognize the changes and will not let you edit the field extraction in the FX UI anymore. You will have to use the props.conf file to make any further changes to the field extraction. Changes made manually cannot be reverted in the FX UI, as the FX UI does not keep track of the changes made in the props.conf file. It is possible to manually edit a regex that was created using the FX UI, as long as you do it in the props.conf file.

Therefore, only statement B is true about manually editing a regex.

The correct answer is B. Reusable pieces of search processing language.

The explanation is as follows:

Search macros are knowledge objects that allow you to insert chunks of SPL into other searches12.

Search macros can be any part of a search, such as an eval statement or a search term, and do not need to be a complete command12.

You can also specify whether the macro field takes any arguments and define validation expressions for them12.

Search macros can help you make your SPL searches shorter and easier to understand3.

To use a search macro in a search string, you need to put a backtick character () before and after the macro name[^1^][1] . For example, mymacro`.

A Search workflow action is the appropriate choice when a user wants to retrieve a specific field value from an event and run a search in a new browser window within their Splunk instance (Option B). This type of workflow action allows users to define a search that utilizes field values from selected events as parameters, enabling more detailed investigation or context-specific analysis based on the original search results.

This search uses the transaction command to group events that share a common value for JSESSIONID into transactions1. The transaction command assigns a duration field to each transaction, which is the difference between the latest and earliest timestamps of the events in the transaction1. The search then uses the timechart command to create a time-series chart of the average duration of each transaction1. Therefore, option A is correct because it describes the search accurately. Option B is incorrect because the search does not use the stats command or the pause field. Option C is incorrect because the transaction command does not require the startswith and endswith options, although they can be used to specify how to identify the beginning and end of a transaction1. Option D is incorrect because the transaction command does not have to be the last command in the search pipeline, although it is often used near the end of a search1.

The transaction command is used to group events into transactions based on some common characteristics, such as fields, time, or both. The transaction command can also specify start and end constraints for the transactions, such as a field value that indicates the beginning or the end of a transaction. The stats command is used to calculate summary statistics on the events, such as count, sum, average, etc. The stats command cannot group events based on start and end constraints, but only on fields or time buckets. Therefore, the transaction command should be used instead of the stats command when you need to group events based on start and end constraints.

A delimiter field extraction is a method of extracting fields from data that uses a character or a string to separate fields in each event. A delimiter field extraction can be performed by using the Field Extractor (FX) tool or by editing the props.conf file. A delimiter field extraction can be applied to any file format that uses a delimiter to separate fields, such as CSV, TSV, PSV, etc. A CSV file is a comma-separated values file that uses commas as delimiters. Therefore, a CSV file can be extracted using a delimiter field extraction.

Event types in Splunk are saved as static search strings. The example index=server_485 sourcetype=BETA_726 code=917 is a simple search that can be saved as an event type, as it does not contain dynamic processing commands like stats or inputlookup, which are not valid for event types.

 There are several ways to access the field extractor. The option that automatically identifies data type, source type, and sample event is Fields sidebar > Extract New Field. The field extractor is a tool that helps you extract fields from your data using delimiters or regular expressions. The field extractor can generate a regex for you based on your selection of sample values or you can enter your own regex in the field extractor. The field extractor can be accessed by using various methods, such as:

Fields sidebar > Extract New Field: This is the easiest way to access the field extractor. The fields sidebar is a panel that shows all available fields for your data and their values. When you click on Extract New Field in the fields sidebar, Splunk will automatically identify the data type, source type, and sample event for your data based on your current search criteria. You can then use the field extractor to select sample values and generate a regex for your new field.

Event Actions > Extract Fields: This is another way to access the field extractor. Event actions are actions that you can perform on individual events in your search results, such as viewing event details, adding to report, adding to dashboard, etc. When you click on Extract Fields in the event actions menu, Splunk will use the current event as the sample event for your data and ask you to select the source type and data type for your data. You can then use the field extractor to select sample values and generate a regex for your new field.

Settings > Field Extractions > New Field Extraction: This is a more advanced way to access the field extractor. Settings is a menu that allows you to configure various aspects of Splunk, such as indexes, inputs, outputs, users, roles, apps, etc. When you click on New Field Extraction in the Settings menu, Splunk will ask you to enter all the details for your new field extraction manually, such as app context, name, source type, data type, sample event, regex, etc. You can then use the field extractor to verify or modify your regex for your new field.

When using a field value variable with a Workflow Action, the exclamation mark (!) will escape the data. A Workflow Action is a custom action that performs a task when you click on a field value in your search results. A Workflow Action can be configured with various options, such as label name, base URL, URI parameters, post arguments, app context, etc. A field value variable is a placeholder for the field value that will be used to replace the variable in the URL or post argument of the Workflow Action. A field value variable is written as fieldn​ame, where field_name is the name of the field whose value will be used. However, if the field value contains special characters that need to be escaped, such as spaces, commas, etc., you can use the exclamation mark (!) before and after the field value variable to escape the data. For example, if you have a field value variable host, you can write it as !$host! to escape any special characters in the host field value.

Therefore, option B is the correct answer.

The timechart command in Splunk requires the _time field to be present in the dataset because it uses time as the primary axis for charting data. The _time field represents the time of events and is essential for commands that generate visualizations based on time, such as timechart. This command groups the events into time intervals and performs statistical functions on those time intervals. Without the _time field, the timechart command will not function properly.

The fillnull command replaces null values in one or more fields with a specified value. The values option allows you to specify a comma-separated list of values to fill the null values in the corresponding fields. The fields option allows you to specify a comma-separated list of fields to apply the fillnull command to. The eval statement in the question uses the if and isnull functions to check if field1 and field2 have null values and replace them with 0 and “NO-VALUE” respectively. The equivalent expression using fillnull is to use the values option to specify 0 and “NO-VALUE” and the fields option to specify field1 and field22

1: Splunk Core Certified Power User Track, page 9. 2: Splunk Documentation, fillnull command.
